DELANEY HARDWARE Italian Collection Briona Single-Cylinder Black Door Handleset with Artino Interior Left-Hand
Original price was: $137.13.$94.99Current price is: $94.99.
Meets ANSI grade 3 lock standards
Lifetime limited manufacturer warranty on the mechanics
5-year limited manufacturer warranty on the finish
- Quality Meets Affordability
- Safe and Secure Shopping
- Safe and Secure Payments, Always
- Safe Payments for a Better Shopping Experience
Inspired by the simple elegance of Venice and timeless beauty of Tuscany, the Delaney Italian Collection Briona Single-Cylinder Black Handleset features clean lines and an enlarged backplate to add style and value to any home. The black finish is neutral to coordinate with a wide range of decor. The upper trim is a single-cylinder deadbolt, operated by a key on the outside and thumb turn on the inside. The inside lower trim is an Artino lever designed for a left-hand door. Handing is determined by standing on the outside of the door, noting on which side the hinges are located. With hinges on the right side, it is a right-hand door. With hinges on the left side, it is a left-hand door.
- Universal installation feature with adjustable latch and interlocking guides for easy installation, requiring only a screwdriver
- All parts and installation instructions included for your convenience
- Reinforced spring assembly for long-lasting, smooth operation
- Internal protective collar for added security
- Fits on both wood and metal doors 1 3/8″ – 1 ¾” thick.
- Mounting hardware included.
| Application Type | Entry |
|---|---|
| Knob/lever bore hole diameter (in.) | 1 |
| Backset Size (in.) | Adjustable |
| Deadbolt Bore Hole Diameter (in.) | 1 in |
| Deadbolt Cross Bore Diameter (in.) | 2.125 in |
| Deadbolt Strike Height (in.) | 2.25 in |
| Deadbolt Strike Width (in.) | 1 in |
| Deadbolt Throw Length (in.) | 1 in |
| Deadbolt Trim Ring Diameter (in.) | 3 in |
| Handle grip length (in.) | 18.375 |
| Inside plate length (in.) | 12 |
| Inside plate width (in.) | 3 |
| Knob/lever cross bore diameter (in.) | 2.125 |
| Assembled Height (in.) | 18.375 in |
| Knob/lever housing height (in.) | 4 |
| Knob/lever housing width (in.) | 4 |
| Knob/lever strike height (in.) | 2.25 |
| Knob/lever strike width (in.) | 1 |
| Knob/lever throw length (in.) | .5 |
| Lever Grip Length (in.) | 4 in |
| Maximum Door Thickness (in.) | 1.75 in |
| Minimum Door Thickness (in.) | 1.375 |
| Outside handle and key plate length (in.) | 18.375 |
| Outside handle and key plate width (in.) | 3 |
| Outside handle plate on-center measurement (in.) | 5.5 |
| Assembled Width (in.) | 4 in |
| Assembled Depth (in.) | 7.25 in |
| Commercial/Residential | Residential |
| Included | Drilling Template,Hardware,Installation Instructions |
| Deadbolt Type | Single Cylinder Deadbolt |
| Deadbolt strike | Round corner |
| Door Handing | Left-Handed |
| Door Lock Style | Rustic |
| Door Locks & Knobs Product Type | Keyed Handlesets |
| Electronic/Mechanical | Mechanical |
| Features | Adjustable Backset,Easy Installation |
| Finish | Black |
| Handleset Product Type | 1 Piece Front & Back |
| Hardware Color Family | Black |
| Hardware Finish Family | Black |
| Interior/Exterior | Interior/Exterior |
| Manufacturer Warranty | Limited Lifetime Mechanical Warranty |
| Keying Type | Keyed Alike |
| Keyway | SC1 |
| Knob/lever strike | Round corner |
| Lever style | Straight |
| Lock Type | Keyed |
| Material | Metal |
| Product Weight (lb.) | 8 lb |
| Returnable | 90-Day |
| Security/ANSI Grade | ANSI Grade 3 (Good) |
| Total Number of Keys Included | 2 |
| Certifications and Listings | ANSI Certified |
| Projection (in.) | 1 |
